| EQUIPMENT INCLUDED : |
ㆍScan Do Select
ㆍAC Line cord
ㆍ6ft. VGA/MAC
ㆍ12ft. S-Video cable
ㆍ12ft BNC output cable |
|
| INPUT/OUTPUT CONNECTORS : |
ㆍHD-15F for Mac input and DB-15 for VGA
input (using supplied reversible input cable)
ㆍ DB-15 for Mac output, HD-15F for VGA output
ㆍComposite video output: BNC connector
ㆍS-Video output: 4-pin mini-DIN-F
ㆍ Remote Control: RS-232 on 3-pin “Phoenix”
type connector
|
|
| INPUTS : |
ㆍHorizontal sync frequency range: 31-71
kHz (320 x 200 to 1280 x 1024), analog RGB,
non-interlaced resolutions
ㆍInput Impedance: RGB - 75 Ohms Sync - high
impedance
ㆍInput Sync Types Supported: Separate H&V,
composite sync (with or without serration),
sync-on-green
ㆍInput Loop-Through: Passive, selfterminating
if not used
|
|
| COMPUTER AND VIDEO PROCESSING: |
ㆍInput sampling: 24-bit (8-bits per RGB)
ㆍSamples: 720 per line
ㆍComputer mode detection: auto measurement
ㆍVideo processing: 16 bit YUV
ㆍVideo memory: 720 x 740 x 16 bits (1 video
frame)
ㆍVideo encoding: 16-bit 4:2:2 YUV with 10-bit
output D/A
ㆍZoom ratios: 0.85x, 1.0x, 1.3x, 1.6x, 2.0x
ㆍDifferential Gain: <1%
ㆍDifferential Phase: <1 degree
ㆍFrequency Response: 6.5 MHz (-3 dB)
|
|
| OUTPUT : |
ㆍComposite and S-Video (simultaneous)
ㆍ NTSC and PAL (switchable)
ㆍVGA and Mac loop-through output
|
|
| POWER : |
ㆍInternal universal input AC power supply
ㆍInput: 100 - 250 VAC, 47 - 63 Hz
ㆍUL/CSA/TUV/CE approved
ㆍIEC 320 connector
ㆍMaximum specified power: 11 Watts
|
|
| DIMENSIONS : |
ㆍ7.25 W x 1.5 H x 8 D (inches)
ㆍ184 W x 38 H x 203 D (mm)
ㆍWeight: Approx. 2 lbs.; 0.9 kg
|
|
|
